उत्पाद विवरण:
|
| शर्त: | नया | लेजर पावर: | 40~60 वाट |
|---|---|---|---|
| कार्य क्षेत्र: | 600mmx400mm | चलती गति: | 0 ~ 50 मिमी / एस |
| पैकेज का आकार: | 1050x650x750 या 1400x650x750 | कुल वजन: | 100~105किग्रा |
| हाई लाइट: | लेजर उत्कीर्णन मशीन,लेजर काटना उपकरण,सीओ 2 लेजर लकड़ी उत्कीर्णन मशीन |
||
Applicable Material
Rubber seals/stamp, oxhorn steel, atomic seal, wood seal, plexiglass seals, etc..
Applicable Industris
Seal/Stamp industries, small craft carving industry etc.
Technical Parameters
|
Laser Power |
40W-50W(optional) |
|
Laser Type |
hermetic co2 glass tube |
|
Power Supply |
AC220±10% 50HZ/AC 110±10% 60HZ |
|
Working Area |
320mm×200mm |
|
Max Moving Speed |
0---500mm/s |
|
Worktable |
honeycomb worktable/up&down worktable |
|
Locating Precision |
＜0.01mm |
|
Min Shaping Character |
character:3×3mm,letter:2×2mm |
|
Operating Temperature |
5℃---35℃ |
|
Resolution Ratio |
≤4500dpi |
|
DataTransfer Interface |
USB(offline) |
|
Svstem Environment |
WINDOWS 2000/WINDOWS XP/Vista/win7/win8 |
|
Cooling Way |
water cooling and protection system |
|
Graphic Format Supported |
the files which CoreDraw,photoshop,AutoCAD can identify(BMP,GIF,JPEG,PCX,TGA,TIFF,PLT,CDR,DMG,DXF,PAT,CDT,CLK,DEX, CSL,CMX,AI,WPG,WMF,EMF,CGM,SVG,SVGZ,PCT,FMV,GEM,CMX) |
|
Compatible software |
CorelDraw,LaserDraw |
|
Cutting Thickness |
0---10mm(depends on different materials) |
|
Cuts off the Water Supply the Protection |
yes |
|
Machine Dimension |
(50w--1050×650×750mm) (60w--1400×650×750mm) |
|
Package Dimension |
(50w--1160×760×900mm) (60w--1660×760×900mm) |
|
New Weight |
50w--90kg 60w—95kg |
|
Gross Weight |
50w--100kg 60w—105kg |
